What Structural Factors Influence the Design of Pre-engineered Industrial Steel Buildings?
2026-10-19
A structural engineer reviews two bids for a 30-meter span Pre-engineered Industrial Steel Buildings project. The first bid uses a welded H-section portal frame with a constant web depth. The second bid uses a built-up tapered frame with a variable web depth and a truss purlin system. The second bid is 35 percent cheaper. The engineer must determine whether the cheaper design meets the structural requirements. The decision depends on the span, the crane load, the wind load, and the snow load. These are the factors that drive the design of pre-engineered steel buildings. This guide explains how each factor influences the frame selection and the steel consumption.
1. How Does Span Affect the Frame Type and Steel Consumption?
The span is the distance between the columns. It is the single most important factor in the design of a Pre-engineered Industrial Steel Buildings. As the span increases, the bending moment in the rafter increases proportionally to the square of the span. The required section modulus increases, and the steel weight per square meter increases. The table below shows the relationship between span and steel consumption for a standard portal frame building with a 6-meter eave height and a 10-degree roof pitch.
| Span (m) | Frame type | Rafter depth (mm) | Steel consumption (kg/m²) |
| 12 – 18 | Constant-depth portal frame | 300 – 400 | 25 – 35 |
| 18 – 24 | Tapered portal frame | 400 – 600 | 30 – 45 |
| 24 – 30 | Tapered portal frame with haunch | 600 – 800 | 40 – 55 |
| 30 – 36 | Truss or deep tapered frame | 800 – 1,200 | 50 – 70 |
| 36 – 45 | Truss frame or two-span frame | 1,200 – 1,800 | 65 – 90 |
For spans up to 18 meters, a constant-depth portal frame is economical. For spans of 18 to 30 meters, a tapered frame with a haunch at the knee is more efficient because the bending moment is highest at the knee and lower at the ridge. For spans above 30 meters, a truss frame or a two-span frame with an intermediate column is usually required. In our factory, we design Pre-engineered Industrial Steel Buildings with spans from 12 to 45 meters. Qingdao Newforge International Trade Co., Ltd. provides span optimization studies for each project.
2. How Do Crane Loads Change the Frame Design?
An overhead crane introduces a concentrated load and a dynamic load to the frame. The crane runway beam transfers the load to the columns, which must be designed for the vertical load, the lateral load, and the longitudinal load. The frame must also be designed for the fatigue effect of the repeated crane cycles. The table below shows the effect of crane capacity on the column and foundation design.
| Crane capacity (tons) | Column type | Foundation type | Steel consumption increase |
| No crane | Standard I-section | Pad footing | Baseline |
| 5 – 10 | Built-up I-section | Pad footing with tie beam | 15 – 25% |
| 10 – 20 | Built-up box section | Pile foundation or raft | 25 – 40% |
| 20 – 50 | Heavy built-up box section | Pile foundation with crane beam | 40 – 60% |
| > 50 | Special design | Engineered foundation | > 60% |
Design engineer's note: The crane load is often the governing factor for the column design, not the wind load or the roof load. A 20-ton crane can increase the steel consumption by 40 percent compared to a building with no crane. The crane runway beam must be designed for the wheel load and the fatigue cycle. In our factory, we design crane runway beams with a fatigue life of 2 million cycles. We also recommend that the crane manufacturer and the building designer coordinate the crane bracket details to avoid unexpected loads.
3. How Do Wind and Snow Loads Affect the Frame Design?
Wind load and snow load are regional factors that change the design of the Pre-engineered Industrial Steel Buildings. Wind load is determined by the basic wind speed, the exposure category, and the building height. Snow load is determined by the ground snow load and the roof geometry. The table below shows the design loads for different regions.
| Region | Basic wind speed (m/s) | Ground snow load (kN/m²) | Design consideration |
| Coastal (typhoon zone) | 45 – 55 | 0 | Wind governs; lateral bracing required |
| Inland (moderate) | 30 – 40 | 0.5 – 1.0 | Balanced wind and snow |
| Northern (snow zone) | 25 – 35 | 1.5 – 3.0 | Snow governs; roof pitch and purlin spacing |
| High altitude | 30 – 40 | 2.0 – 4.0 | Snow and wind; increased roof slope |
In a coastal typhoon zone, the wind load governs the design of the lateral bracing and the column anchorage. The roof purlins must be designed for uplift. In a northern snow zone, the snow load governs the design of the roof purlins and the rafter. The roof pitch must be steep enough to shed snow, and the purlin spacing must be reduced to prevent ponding. In our factory, we use a structural analysis software that incorporates the local wind and snow data. Qingdao Newforge International Trade Co., Ltd. provides a site-specific load calculation for each project.
4. What Other Factors Influence the Design of Pre-engineered Steel Buildings?
There are three other factors that influence the design of Pre-engineered Industrial Steel Buildings: the eave height, the bay spacing, and the roof slope. The eave height determines the column height and the wind exposure. The bay spacing determines the number of frames and the purlin span. The roof slope determines the drainage and the snow shedding. The table below shows the typical ranges and their effects.
| Factor | Typical range | Effect on design |
| Eave height | 4 – 12 m | Higher eave increases wind moment and column size |
| Bay spacing | 6 – 9 m | Wider bay increases purlin and frame load |
| Roof slope | 5 – 15% | Steeper slope improves drainage but increases wind uplift |
| Roof dead load | 0.15 – 0.30 kN/m² | Includes roofing, insulation, and purlins |
| Live load | 0.5 – 1.0 kN/m² | For maintenance access; not for storage |
In our factory, we optimize the bay spacing to minimize the total steel weight. A bay spacing of 7.5 meters is often the most economical for a 30-meter span building. A wider bay reduces the number of frames but increases the purlin size. A narrower bay reduces the purlin size but increases the number of frames. The optimum is determined by a cost analysis. Qingdao Newforge International Trade Co., Ltd. provides this analysis as part of our design service.
Frequently Asked Questions About Structural Factors in Pre-engineered Steel Buildings
Summary for Structural Engineers and Project Managers
The design of Pre-engineered Industrial Steel Buildings is influenced by the span, the crane load, the wind load, the snow load, the eave height, the bay spacing, and the roof slope. The span determines the frame type and the steel consumption. The crane load governs the column and foundation design. The wind and snow loads are regional factors that change the bracing and the purlin design. By understanding these factors, engineers can select the most economical and reliable structural system for each project. Qingdao Newforge International Trade Co., Ltd. has been designing and supplying pre-engineered steel buildings for over 15 years and provides full structural engineering support for our customers.
